Nanovna V2 - 3Ghz Vector Network Analyzers

Nanovna V2 - 3Ghz Vector Network Analyzers
3GHz second generation nanoVNA Vector Network Analyzers

Nanovna V2

Nanovna V2 - 3Ghz Vector Network Analyzers
3GHz second generation nanoVNA Vector Network Analyzers

Specifications:
Frequency range: 50kHz - 3GHz
System dynamic range (calibrated): 70dB (up to 1.5GHz), 60dB (up to 3GHz)
S11 noise floor (calibrated): -50dB (up to 1.5GHz), -40dB (up to 3GHz)
Sweep rate: 100 points/s
Display: 2.8'', 320 x 240
USB interface: Micro USB
Power: USB, 300mA
Battery connector: JST-XH 2.54mm
Maximum sweep points (on device): 201
Maximum sweep points (USB): 1024
VNA-QT software supported platforms: Linux, Windows (7+), Mac OS planned
(nanoVNA Saver software soon available)













Amateur HAM Radio Hotspots Canada

Amateur HAM Radio VE3SP Hotspots

P25 + DMR + DSTAR + FUSION + NXDN
Hotspots
P25 + DMR + DSTAR + FUSION + NXDN
It's in my jacket

FEAR - Motivational Video (Les Brown)

FEAR - Motivational Video (Les Brown)

Attached video in the READ MORE link


Attached video in the READ MORE link

DSO188 matchbox oscilloscope

DSO188 matchbox oscilloscope

(Published on 27/10/2018)

With its dimensions of 57 mm by 34 mm by 11 mm you can call Daniu's DSO188 a matchbox oscilloscope. If you think this device is nothing more than a funny, but useless toy you are wrong. It allows you to observe signals up to 100 kHz. W

Anyone looking for a low cost scope to trouble shoot (a least audio and low frequency such as encoders) parts of their UBitx, these little oscilloscopes were on sale. I bought one. It only has a 1 Mhz bandwidth, but that is better than the 200 Khz bandwidth on many of the other cheap tiny scopes.

Pi-Star (increase) - Dashboard - Gateway Activity Screen Section

Pi-Star (increase) - Dashboard - Gateway Activity Screen Section

I would like to offer a suggestion for the Pi-Star software. I believe this is something that would benefit more hams than just myself, especially Net Control operators.

Concerning the Gateway Activity screen. Is it possible to have a configuration setting to allow the user to set more than 20 rows of activity. Displaying a vertical scroll bar on the right to go back and retrieve calls that have rolled off the screen? On the left side of the row, the number of rows desired would be set in the cofiguration menu. There is plenty of room on the left where the time is displayed to number each row so you can scroll backwards to look at any call signs that were missed because of the roll off.


VA3IER - BE PHENOMENAL

Today is my day.  BE PHENOMENAL


An inspiring motivational video featuring motivational speeches

more Motivational video

NanoVNA vs Conventional Antenna Analyzer - MFJ-259C or Rig Expert AA-600

NanoVNA vs Conventional Antenna Analyzer - MFJ-259C or Rig Expert AA-600

I bought an MFJ-259C a few years ago. Cost me about $550. It’s ok but a bit poor quality. Rig Expert are better for sure, but I wouldn’t buy a conventional antenna analyzer any more. The Nano VNA is the way to go and dirt cheap. Like US$50. There’s one with a larger screen now too for a bit more that’s worth the extra money in my opinion.

There was a detailed review in QST in one of the recent issues (last three months – I forget which one).

They tested it and found it as good as ones 10x the price.
https://www.youtube.com/watch?v=8kx9SWbEcXI
It’s a whole new world of possibilities!


The NanoVNA: A $50 Vector Network Analyzer


IC-9700 VHF/UHF Transceiver - Icom

IC-9700 VHF/UHF Transceiver - Icom

I own and enjoy using ..

Built with the VHF/UHF weak signal operator in mind, the IC-9700 is an RF direct sampling receiver for 2m and 70cm



Motivation for success & Gym

Motivation for success & Gym

A very powerful video

See included attached video in the READ MORE link below
